STU (Shock Transmission Unit) / LUD (Lock-Up Device)

Structure and Principle

The internal mechanism of an STU operates using high-viscosity fluid and a piston to control its mechanical behavior, featuring the characteristic of 「Slow Movement, Rapid Locking」. It permits slow displacements caused by temperature changes or creep during normal conditions, thereby avoiding restraint stress. When an earthquake or an instantaneous external force occurs, it instantaneously locks the structural connection, effectively transferring horizontal forces to the primary supporting members.

Product Features

• Instantaneous Stiffness Transfer

• Allows for Long-Term Displacement

• Maintenance-Free Design

• High Response Sensitivity

• Effective Elimination of Resonance Energy

• Compatible with Multiple Bearing Systems

• Available in various Capacities and Strokes

• High Reliability and Stability

Why STUs are Essential for Bridges:

• Seismic Survival: Their most critical function is earthquake mitigation. STUs rapidly absorb and dissipate massive kinetic energy during tremors, preventing catastrophic joint failure and preserving the structural connection integrity.

• Impact Protection: They safeguard joints from sudden, extreme forces caused by high winds or accidental impacts, limiting destructive travel ranges.

• Longevity: By controlling shock, STUs protect adjacent bearings and seals from premature wear, drastically extending the operational lifespan of the entire bridge system.

Our Commitment to Bridge Safety:

• High Energy Dissipation: We design units capable of safely absorbing and dissipating extreme kinetic energy, perfectly meeting rigorous seismic event specifications.

• Custom Damping: We tailor the internal valving system to achieve the precise engagement curve required by your bridge design specifications.

• Rugged Durability: Our products feature a robust structure, capable of withstanding continuous environmental exposure and high loads, ensuring a long service life and minimal maintenance.

Secure your bridge investment with the proven reliability of Brant Hydraulic STUs.

We do have many other types of dampers products available for different needs.

Please Contact us or Email us for more details.
